1FK7060-2AH71-1QH1 SIEMENS Exclusive SIMOTICS S-1FK7 Original Brand New

1FK7060-2AH71-1QH1 SIEMENS Exclusive SIMOTICS S-1FK7 Original Brand New

This is a high-performance synchronous motor designed for modern automation applications. Delivering 1.7 kW of power with a nominal voltage of 600 V and a rated torque of 6 Nm, this motor operates at 4500 rpm with a naturally cooled construction, making it reliable for continuous duty. The IMB 5 (IM V1, IM V3) design and flange 1 mounting allow easy integration into various machine assemblies. The motor includes a rotatable power connector and an absolute single-turn 20-bit encoder with DRIVE-CLiQ interface (AS20DQI), ensuring precise speed and position control.

Overview

The motors are compact permanent-magnet synchronous motors engineered for maximum flexibility. With a wide range of available options including gearboxes and encoder variants, these motors can be adapted to meet the requirements of cutting-edge machinery. They pair seamlessly with the SINAMICS S120/S220 drive systems, creating a highly functional and responsive automation solution. Heat dissipation occurs naturally through the motor surface, eliminating the need for external cooling while maintaining high overload capability.

Benefits

The series offers space-efficient installation due to high power density and a broad selection of motor variants suitable for universal applications. High dynamic models provide extremely fast response times thanks to low rotor inertia, while high inertia variants deliver robust closed-loop performance for heavy or varying load moments. These motors minimize commissioning and optimization efforts by compensating efficiently for disturbances during operation.

Applications

Designed for diverse industrial sectors, the motor is ideal for machine tools, robotic handling systems, and automation machinery. It is well-suited for applications in wood, glass, ceramics, and stone processing, as well as packaging, plastics, textile, and printing machines. Auxiliary axes also benefit from its precise control and reliable performance.

Download

Data Sheet (PDF)

Product Code: 1FK7060-2AH71-1QH1
