6GK5334-3TS00-3AR3 SIEMENS SCALANCE XR322-12 Exclusive Managed IE Switch Brand New Original

6GK5334-3TS00-3AR3 SIEMENS SCALANCE XR322-12 Exclusive Managed IE Switch Brand New Original

SCALANCE XR322-12 managed Layer 2 IE switch; 19" rack-mountable; 20x 100/1000 Mbps RJ45 ports; 2x 1G/2.5G/5G/10G RJ45 ports; 4x 100M/1G SFP ports; 8x 1G/10G SFP+ ports; LED diagnostics; error signaling contact; select/set button; PROFINET IO device; network management; integrated redundancy manager; office features (RSTP, VLAN, IGMP); CLP included; 230 V AC power supply

Overview

The Siemens SCALANCE XR322-12 (6GK5334-3TS00-3AR3) is an exclusive 19-inch rack-mounted managed Layer 2 Industrial Ethernet switch from the XR-300 series, designed for high-performance industrial networks with data rates up to 10 Gbps. It features 20 Fast/Gigabit RJ45 ports, 2 multi-rate RJ45 uplinks (up to 10 Gbps), 4 SFP ports for 100M/1G optical links, and 8 SFP+ ports for 1G/10G uplinks.

This variant operates on 230 V AC and supports PROFINET IO diagnostics, integrated redundancy protocols, and advanced VLAN segmentation. With LED diagnostics, CLP configuration memory, and rugged IP20 housing, the XR322-12 is an exclusive solution for scalable, secure, and resilient industrial automation infrastructure.

Key Features

• 20 x 100/1000 Mbps RJ45 electrical ports
• 2 x 1G/2.5G/5G/10G RJ45 multi-rate uplink ports
• 4 x 100M/1G SFP ports
• 8 x 1G/10G SFP+ ports for optical uplinks
• IEC 62443-4-2 certified; PROFINET IO and EtherNet/IP compatible
• Integrated redundancy manager (MRP, HRP, RSTP, PRP, HSR)
• LED diagnostics and select/set pushbutton
• Console port and signaling contact
• VLAN, IGMP snooping, ACL, IEEE 802.1X
• 230 V AC power supply via IEC plug
• IP20 metal enclosure; fanless design
• Operating temperature: –25 °C to +60 °C
• 19" rack-mountable; low installation depth

Product Code: 6GK5334-3TS00-3AR3 More Siemens products at Turll.com
