Siemens 3RT2317-2AK60 SIRIUS Contactor AC-1, 22A, 4-Pole, S00 Spring-Loaded Terminal, 110/120V AC Coil Original Brand New

Siemens 3RT2317-2AK60 SIRIUS Contactor

The Siemens 3RT2317-2AK60 is a high-performance SIRIUS power contactor designed for reliable switching of AC-1 (non-inductive) loads. Part of the renowned Siemens SIRIUS modular system, this 4-pole contactor offers exceptional durability and versatility for a wide range of industrial control applications. Its compact S00 size and user-friendly spring-loaded terminals ensure easy integration and secure connections.

Overview

The 3RT2317-2AK60 is a 4-pole contactor specifically engineered for AC-1 applications, handling currents up to 22A at 400V / 40°C. It features a robust 110V AC (50Hz) / 120V AC (60Hz) coil for precise control. This contactor is an ideal solution for switching weak or non-inductive loads, disconnecting loads, and managing power generation plants. It adheres to stringent international standards, including IEC 60947-1, IEC 60947-4-1, and IEC 60947-5-1 (for auxiliary switches), ensuring reliable and safe operation within your electrical systems.

Key Features & Benefit

• Optimized for AC-1 Applications: Designed for switching non-inductive or slightly inductive loads, offering stable performance for resistive heating, lighting, and similar applications.
• High Current Capacity: Handles up to 22A at 400V/40°C, providing ample capacity for various loads.
• 4-Pole Configuration: Provides versatile switching capabilities for multi-phase systems or complex control circuits.
• Compact S00 Size: Space-saving design allows for efficient use of panel space, especially in confined enclosures.
• Spring-Loaded Terminals: Ensures fast, reliable, and vibration-proof connections without the need for tools, reducing installation time and maintenance.
• Wide Voltage Compatibility: Features a dual-frequency coil (110V AC 50Hz / 120V AC 60Hz) for flexible integration into different power systems.
• Robust & Reliable: Built to Siemens’ high-quality standards, guaranteeing long-term operational stability and reduced downtime.
• Modular SIRIUS System: Seamlessly integrates with other Siemens SIRIUS components, including overload relays (3RU2 thermal, 3RB3/3RB2 electronic) for comprehensive motor protection.
• Enhanced Safety: Complies with major international standards (IEC 60947-series) for industrial control equipment.
• Accessory Expandability: Supports the addition of various accessories, including surge suppressors (RC elements, varistors, diodes) and auxiliary switches for increased functionality and customization.

Function

• Four-Pole Switching: Capable of switching four independent circuits or phases simultaneously.
• Load Disconnection: Effectively disconnects weak or non-inductive loads from the grid.
• Power Generation Plant Integration: Suitable for transfer switching and managing power flow in generation systems.
• Control Circuit Integration: Functions as a key component in industrial control panels for automated processes.

Standards & Protection:

The Siemens 3RT2317-2AK60 contactor adheres to rigorous international standards:

• IEC 60947-1: General rules for low-voltage switchgear and control gear.
• IEC 60947-4-1: Contactors and motor-starters.
• IEC 60947-5-1: Control circuit devices and switching elements (for auxiliary switches).

Protection Measures:

• Short-Circuit and Overload Protection: All connections (main, auxiliary, control supply) must be protected using appropriate measures, such as fuses or circuit breakers. Refer to the technical product data sheet and configuration manuals for detailed guidance.
• Overvoltage Protection (Coil): The 3RT23 contactors can be retrofitted with external surge suppressors (RC elements, varistors, diodes) to dampen opening surges in the coil, protecting sensitive control circuitry.

Connection Methods:

• Main Circuit: Features convenient spring-loaded terminals, providing secure and tool-free wiring.
• Auxiliary and Control Circuit: Utilizes screw terminals for reliable connections.

Electromagnetic Compatibility (EMC):

The contactor fulfills the requirements for environment category A, ensuring stable operation in typical industrial settings. When used with frequency converters, refer to the Equipment Manual for specific configuration notes.

Contact Reliability of Auxiliary Contacts:

The integrated auxiliary contacts are designed for high reliability, particularly for switching low voltages (≤ 110 V) and currents (≤ 100 mA), making them ideal for solid-state circuits (≥ 1 mA at ≥ 17 V).

Motor Protection Compatibility:

While designed for AC-1 loads, the 3RT23 contactor can be combined with Siemens 3RU2 thermal overload relays or 3RB3 electronic overload relays for comprehensive protection of connected motors (when used in AC-3 applications).

Operating Mechanism:

• Conventional AC Operating Mechanism: This version features a reliable AC operating mechanism, controlled via the A1-A2 control supply voltage connection.

Maintenance & Expandability:

• Replaceable Solenoid Coil: The solenoid coil can be easily replaced, extending the lifespan of the contactor.
• Auxiliary Contact Expansion: The basic unit of the 3RT231 contactor includes one integrated auxiliary contact. This can be expanded with additional auxiliary switches for increased signaling and control capabilities.

Accessories and Spare Parts:

A wide range of accessories and spare parts are available for SIRIUS 3RT2 contactors and 3RH2 contactor relays, including:

• Surge suppressors
• Auxiliary switches (instantaneous)
• Replacement solenoid coils

For a complete overview of mountable accessories, refer to the Siemens documentation or Turll.com.

Application

The Siemens 3RT2317-2AK60 contactor is ideal for various industrial and commercial applications, including:

• Switching of non-inductive or weakly inductive loads (AC-1)
• Control of heating elements
• Lighting systems
• Power distribution circuits
• Disconnecting loads from the grid
• Transfer switching in power generation plants
• Integration into control panels for automated processes

For more Siemens industrial control products and solutions, visit Turll.
