Siemens 6ES7193-6BP00-0BA0 SIMATIC ET 200SP BaseUnit (BU15-P16+A0+2B) Original Brand New

Overview

The SIMATIC ET 200SP BaseUnit BU15-P16+A0+2B (6ES7193-6BP00-0BA0) serves as the mechanical and electrical foundation for ET 200SP peripheral modules. In the modern landscape of industrial automation, space-saving designs and rapid wiring are critical. Siemens addresses these needs by utilizing "Push-in" technology, which allows for tool-free wiring, significantly reducing installation time and labor costs.

This specific BaseUnit is classified as Type A0, meaning it is compatible with a wide range of digital and analog input/output modules.⁴ The "bridged to the left" configuration is a key architectural feature, allowing the internal bus and power supply to continue from the previous module, eliminating the need for redundant external wiring. With a slim profile of just 15mm, it is designed for high-density control panels where every millimeter counts.

Key Benefit

• Time-Saving Installation: The push-in terminal system allows for solid wires or finely stranded wires with end sleeves to be inserted directly without the use of tools.

• Space Efficiency: With a width of only 15mm and a height of 117mm, this BaseUnit allows for more I/O points in a smaller footprint compared to traditional modular systems.

• Reduced Wiring Complexity: Because the unit is bridged to the left, the potential for the supply voltage is automatically distributed across the station, minimizing the number of cables required.

• Hot-Swapping Capability: The permanent wiring design allows I/O modules to be replaced during operation (hot-swapping) without disturbing the wiring of the BaseUnit itself.

• High Reliability: Built to Siemens’ rigorous industrial standards, ensuring long-term durability in harsh electromagnetic environments.

Product Function

The primary function of the 6ES7193-6BP00-0BA0 is to provide the electrical connection between the ET 200SP backplane bus and the process signals.

1. Electrical Connectivity: It houses 16 process terminals for signal interfacing.

2. Power Distribution: It continues the voltage group from the neighboring module on the left, ensuring a continuous supply of 24 V DC across the peripheral modules.

3. Mechanical Support: It provides the DIN rail mounting interface and the locking mechanism for the I/O module.

4. Identification: Features integrated slots for color-coded labels and reference identification labels, aiding in maintenance and troubleshooting.

Technical Application

The Siemens SIMATIC ET 200SP system is widely used across various industries due to its modularity. The 6ES7193-6BP00-0BA0 BaseUnit is typically applied in:

• Automotive Manufacturing: Managing high-speed digital signals on assembly lines.

• Food & Beverage: Control systems for packaging and processing where hygiene and compact design are necessary.

• Water & Wastewater: Distributing I/O for remote monitoring stations.

• Machine Building (OEMs): Integrating complex logic into small control boxes for specialized machinery.

• Energy Management: Monitoring power parameters when paired with compatible ET 200SP energy meters.

Installation and Maintenance

Installing the 6ES7193-6BP00-0BA0 is straightforward. The unit snaps onto a standard TH35 DIN rail. When building an ET 200SP station, this BaseUnit is placed to the right of a "Light" BaseUnit (which starts a new potential group) or another "Dark" BaseUnit (which continues the group).

Maintenance is simplified by the permanent wiring concept. If a module fails, the BaseUnit remains on the DIN rail with all wires intact. You simply pull the module out and click a new one in, reducing downtime to seconds rather than minutes.

Download

Datasheet in PDF

Visit 6ES7193-6BP00-0BA0 for more detail info

For more our products visit turll
